Application For
Intel
LGA2066/2011-v3/2011/1700/1200/1151/1150/1155
AMD
AM5/AM4
Technical Spec
Product Dimensions
144×147×164 mm(L×W×H)
Heatsink Dimensions
140×110×160 mm(L×W×H)
Net Weight
1575 g
Heatpipe
O6 mm×7 pcs
Fan Dimensions
140×140×25 mm(L×W×H) / 120×120×25 mm(L×W×H)
Fan Speed (Performance Mode)
500~1700 RPM±10%
Fan Airflow (Performance Mode)
79.1 CFM / 58.06 CFM
Fan Air Pressure (Performance Mode)
2.44 mmAq / 2.1 mmAq
Overall Noise (Performance Mode)
≤29.3 dB(A)
Fan Speed (Quiet Mode)
500~1350 RPM±10%
Fan Airflow (Quiet Mode)
63.76 CFM / 46.75 CFM
Fan Air Pressure (Quiet Mode)
1.58 mmAq / 1.35 mmAq
Overall Noise (Quiet Mode)
≤22.6 dB(A)
Fan Connector
4-pin PWM
Bearing Type
Fluid Dynamic Bearing
Motor Type
6-Pole Fan Motor
Fan Rated Voltage
12 VDC
Fan Rated Current
0.3 A / 0.2 A
Fan Power Consumption
3.6 W / 2.4 W
Rated Voltage
12 VDC
Power Consumption(Performance Mode)
6 W
Power Consumption(Quiet Mode)
3.6 W
EAN
6933412728382
P/N
R-ASN4-WHNNMT-G
Application For Intel LGA2066/2011-v3/2011/1700/1200/1151/1150/1155 AMD AM5/AM4 Technical Spec Product Dimensions 144×147×164 mm(L×W×H) Heatsink Dimensions 140×110×160 mm(L×W×H) Net Weight 1575 g Heatpipe O6 mm×7 pcs Fan Dimensions 140×140×25 mm(L×W×H) / 120×120×25 mm(L×W×H) Fan Speed (Performance Mode) 500~1700 RPM±10% Fan Airflow (Performance Mode) 79.1 CFM / 58.06 CFM Fan Air Pressure (Performance Mode)
Application For Intel LGA2066/2011-v3/2011/1700/1200/1151/1150/1155 AMD AM5/AM4 Technical Spec Product Dimensions 144×147×164 mm(L×W×H) Heatsink Dimensions 140×110×160 mm(L×W×H) Net Weight 1575 g Heatpipe O6 mm×7 pcs Fan Dimensions 140×140×25 mm(L×W×H) / 120×120×25 mm(L×W×H) Fan Speed (Performance Mode) 500~1700 RPM±10% Fan Airflow (Performance Mode) 79.1 CFM / 58.06 CFM Fan Air Pressure (Performance Mode)
Application For Intel LGA2066/2011-v3/2011/1700/1200/1151/1150/1155 AMD AM5/AM4 Technical Spec Product Dimensions 116×147×164 mm(L×W×H) Heatsink Dimensions 140×110×160 mm(L×W×H) Net Weight 1380 g Heatpipe O6 mm×7 pcs Fan Dimensions 140×140×25 mm(L×W×H) Fan Speed (Performance Mode) 500~1800 RPM±10% Fan Airflow (Performance Mode) 61.25 CFM Fan Air Pressure (Performance Mode) 3.76 mmAq Overall Noi
Application For Intel LGA2066/2011-v3/2011/1700/1200/1151/1150/1155 AMD AM5/AM4 Technical Spec Product Dimensions 116×147×164 mm(L×W×H) Heatsink Dimensions 140×110×160 mm(L×W×H) Net Weight 1380 g Heatpipe O6 mm×7 pcs Fan Dimensions 140×140×25 mm(L×W×H) Fan Speed (Performance Mode) 500~1800 RPM±10% Fan Airflow (Performance Mode) 61.25 CFM Fan Air Pressure (Performance Mode) 3.76 mmAq Overall Noi
Application For Intel LGA2066/2011-v3/2011/1700/1200/1151/1150/1155 AMD AM5/AM4 Technical Spec Product Dimensions 116×147×164 mm(L×W×H) Heatsink Dimensions 140×110×160 mm(L×W×H) Net Weight 1380 g Heatpipe O6 mm×7 pcs Fan Dimensions 140×140×25 mm(L×W×H) Fan Speed (Performance Mode) 500~1800 RPM±10% Fan Airflow (Performance Mode) 61.25 CFM Fan Air Pressure (Performance Mode) 3.76 mmAq Overall Noi
Application For Intel LGA2066/2011-v3/2011/1700/1200/1151/1150/1155 AMD AM5/AM4 Technical Spec Product Dimensions 116×147×164 mm(L×W×H) Heatsink Dimensions 140×110×160 mm(L×W×H) Net Weight 1380 g Heatpipe O6 mm×7 pcs Fan Dimensions 140×140×25 mm(L×W×H) Fan Speed (Performance Mode) 500~1800 RPM±10% Fan Airflow (Performance Mode) 61.25 CFM Fan Air Pressure (Performance Mode) 3.76 mmAq Overall Noi
Application For Intel LGA1700/1200/1151/1150/1155 AMD AM5/AM4 Technical Spec Product Dimensions 125×92×150 mm Heatsink Dimensions 120×92×150 mm Net Weight 614 g Heatpipe O6 mm×4 pcs Fan Dimensions 120×120×25 mm Fan Speed 500~2000 RPM±10% Fan Airflow 75.89 CFM Fan Air Pressure 2.53 mmAq Fan Noise ≤31.6 dB(A) Fan Connector 4-pin PWM Bearing Type Hydro Bearing
Application For Intel LGA1700/1200/1151/1150/1155 AMD AM5/AM4 Technical Spec Product Dimensions 125×92×150 mm Heatsink Dimensions 120×92×150 mm Net Weight 614 g Heatpipe O6 mm×4 pcs Fan Dimensions 120×120×25 mm Fan Speed 500~2000 RPM±10% Fan Airflow 75.89 CFM Fan Air Pressure 2.53 mmAq Fan Noise ≤31.6 dB(A) Fan Connector 4-pin PWM Bearing Type Hydro Bearing
Product Dimensions 129×138×160 mm Heatsink Dimensions 127×110×157 mm Net Weight 1456 g Heatpipe O6 mm×6 pcs Fan Dimensions 120×120×25 mm Fan Speed 500~1850 RPM±10% Fan Airflow 68.99 CFM Fan Air Pressure 2.19 mmAq Fan Noise ≤28 dB(A) Fan Connector 4-pin PWM Bearing Type Fluid Dynamic Bearing Fan Rated Voltage 12 VDC
Product Dimensions 129×138×160 mm Heatsink Dimensions 127×110×157 mm Net Weight 1456 g Heatpipe O6 mm×6 pcs Fan Dimensions 120×120×25 mm Fan Speed 500~1850 RPM±10% Fan Airflow 68.99 CFM Fan Air Pressure 2.19 mmAq Fan Noise ≤28 dB(A) Fan Connector 4-pin PWM Bearing Type Fluid Dynamic Bearing Fan Rated Voltage 12 VDC
Application For Intel LGA1700/1200/1151/1150/1155 AMD AM5/AM4 Product Dimensions 127×97×155 mm Heatsink Dimensions 120×45×152 mm Net Weight 661 g Heatpipe O6 mm×4 pcs Fan Dimensions 120×120×25 mm Fan Speed 500~1850 RPM±10% Fan Airflow 66.47 CFM Fan Air Pressure 2.04 mmAq Fan Noise ≤29 dB(A) Fan Connector 4-pin PWM Bearing Type Fluid Dynamic Bearing Fan
Application For Intel LGA1700/1200/1151/1150/1155 AMD AM5/AM4 Product Dimensions 127×97×155 mm Heatsink Dimensions 120×45×152 mm Net Weight 661 g Heatpipe O6 mm×4 pcs Fan Dimensions 120×120×25 mm Fan Speed 500~1850 RPM±10% Fan Airflow 66.47 CFM Fan Air Pressure 2.04 mmAq Fan Noise ≤29 dB(A) Fan Connector 4-pin PWM Bearing Type Fluid Dynamic Bearing Fan
Product Dimensions 127×97×155 mm Heatsink Dimensions 120×45×152 mm Net Weight 661 g Heatpipe O6 mm×4 pcs Fan Dimensions 120×120×25 mm Fan Speed 500~1850 RPM±10% Fan Airflow 66.47 CFM Fan Air Pressure 2.04 mmAq Fan Noise ≤29 dB(A) Fan Connector 4-pin PWM Bearing Type Fluid Dynamic Bearing Fan Rated Voltage 12 VDC Fan Rated Current 0.13 A Fan Powe
Product Dimensions 127×97×155 mm Heatsink Dimensions 120×45×152 mm Net Weight 661 g Heatpipe O6 mm×4 pcs Fan Dimensions 120×120×25 mm Fan Speed 500~1850 RPM±10% Fan Airflow 66.47 CFM Fan Air Pressure 2.04 mmAq Fan Noise ≤29 dB(A) Fan Connector 4-pin PWM Bearing Type Fluid Dynamic Bearing Fan Rated Voltage 12 VDC Fan Rated Current 0.13 A Fan Powe
Application For Intel LGA1700/1200/1151/1150/1155 AMD AM5/AM4 Technical Spec Product Dimensions 119×77×133 mm Heatsink Dimensions 94×57×133 mm Net Weight 350 g Heatpipe O6 mm×3 pcs Fan Dimensions 92×92×25 mm Fan Speed 500~3050 RPM±10% Fan Airflow 36.75 CFM Fan Air Pressure 2.89 mmAq Fan Noise ≤30.5 dB(A) Fan Connector 4-pin PWM Bearing Type Hydro Bearing
