Technical Spec
Net Weight
1346 g
Radiator Dimensions
282×120×27 mm(L×W×H)
Radiator Material
Aluminum
Tube length
410 mm
Pump Dimensions
85×73×55 mm(L×W×H)
Pump Speed
3100 RPM±10%
Pump Noise
19 dB(A)
Pump Connector
3-pin
Pump Rated Voltage
12 VDC
Pump Rated Current
0.5A
Pump Power Consumption
6W
Fan Dimensions
120×120×25 mm(L×W×H)
Fan Speed
500~2250 RPM±10%
Fan Airflow
85.85 CFM
Fan Air Pressure
3.27 mmAq
Fan Noise
≤32.9 dB(A)
Fan Speed (with LSP)
500~1600 RPM±10%
Fan Airflow (with LSP)
60.85 CFM
Fan Air Pressure (with LSP)
1.65 mmAq
Fan Noise (with LSP)
≤28.2 dB(A)
Fan Connector
4-pin PWM
Bearing Type
Hydro Bearing
Fan Rated Voltage
12 VDC
Fan Rated Current
0.25 A
Fan Power Consumption
3.0 W
LED Type
White LED
EAN
6933412728429
P/N
R-LS520-BKNNMM-G-1
