Technical Spec
Type
ATX12V V2.4
Product Dimensions
150×140×86mm (W x L x H)
80PLUS Certifications
230V EU White
Fan Size
120mm
Fan Bearing
Hypro Bearing
Topology
Active PFC+Double tube forward
Capacitors
Taiwan bulk capacitor
Power Good Signal
100-500ms
Hold Up Time
≥16ms(75% Load)
Efficiency
≥85% Under Typical Load(50% Loading)
Protection
OPP/OVP/SCP/UVP
Operation Temperature
0-30°C
Regulatory
CB/CCC/CE/UKCA/EAC/RCM/BIS
Erp Regulation
ErP 2010
MTBF
100,000 Hours
EAN P/N
6933412711360 R-PF600D-HA0B-AU
6933412711377 R-PF600D-HA0B-AR
6933412711384 R-PF600D-HA0B-CN
6933412711391 R-PF600D-HA0B-EU
6933412711407 R-PF600D-HA0B-UK
6933412711414 R-PF600D-HA0B-WO
6933412711421 R-PF600D-HA0B-BP
6933412711698 R-PF600D-HA0B-US
