Emulex 8Gb Fibre Channel Single-port HBA ( 42D0485 )
Főbb tulajdonságok:
Befogadó csatlakozó
PCIe
Output interface
Fibre
Portok száma
1
Kapcsolódási technológia
Wired
Teljes kétoldalú
Igen
Macintosh kompatibilitás
Nem
Üzemi hőmérséklettartomány (T-T)
0 - 55°C
Tárolási hőmérséklettartomány (T-T)
-40 - 70°C
Relatív üzemi páratartalom-tartomány
5 - 95%
Leírás eredeti nyelven: US
Industry Standards
Current ANSI/IETF Standards: FC-PI-4; FC-PI-5; FC-FS-2 with amendment 1; FC-AL-2 with amendments 1 and 2; FC-LS-2; FC-GS-6; FC-DA; FC-SP-2; FCP-4; FC-MJS; FC-SB-4; FC-SP; SPC-4; SBC-3; SSC-3; RFC4338
Legacy ANSI/IETF standards: FC-PH; FC-PH-2; FC-PH-3; FC-PI; FC-PI-2; FC-FS; FC-AL; FC-GS-2/3/4/5; FCP; FCP-2; FC-SB-2; FC-FLA; FC-HBA; FC-PLDA; FC-TAPE; FC-MI; SPC-3; SBC-2; SSC-2; RFC2625
PCIe base spec 2.0
PCIe card electromechanical spec 2.0
Fibre Channel class 2 and 3
PHP hot plug-hot swap
Architecture
Single-channel (IBM 81Y1655) or dual-channel (IBM 81Y1662)
Supports 16GFC, 8Gb FC and 4Gb FC link speeds, automatically negotiated
Supports up to 2 FC ports at 16Gb FC max (dual port model)
Integrated data buffer and code space memory
Comprehensive OS Support
Windows
Linux
Solaris
VMware ESX/ESXi
Additional support is available from OEMs and partners
Hardware Environments
PowerPC, SPARC, x86, x64 and Intel Itanium 64-bit processor family
Optical
Data rates: 14.025 Gb/s (1600Mb/s); 8.5 Gb/s (800Mb/s); 4.25 Gb/s (400 Mb/s) (auto-detected)
Optics: Short wave lasers with LC type connector
Cable: Operating at 16Gb
15m at 16Gb on 62.5/125 μm OM1 MMF
35m at 16Gb on 50/125 μm OM2 MMF
100m at 16Gb on 50/125 μm OM3 MMF
125m at 16Gb on 50/125 μm OM4 MMF
Physical Dimensions
Short, low profile MD2 form factor card
167.64mm x 68.91mm (6.60” x 2.71”)
Standard bracket (low profile available)
Power Environmental Requirements
Power supply 1.8V, 1.2V, 0.9V
Volts: +3.3, +12
Operating temperature: 0° to 55° C (32° to 131° F)
Storage temperature: -40° to 70° C (-40° to 158° F)
Relative humidity: 5% to 95% non-condensing
23° C wet bulb
Agency and Safety Approvals
Class 1 Laser Product per DHHS 21CFR (J) and EN60825-1*
UL recognized to UL 60950-1 2nd edition
cUR recognized to CSA22.2, No. 60950-1-07
TUV Bauart-certified to EN60950-1:2006 +A11+A1+A12
FCC Part 15, Class A
ICES-003:2012, Class A
EMC Directive 2004/108/EC (CE Mark)
EN55022:2010, Class A
EN55024:2010
Australian EMC Framework (C-Tick Mark)
AS/NZS CISPR:2009 +A1, Class A
VCCI Class A
BSMI Class A
CNS13438:2006 (complete)
MSIP (formally KCC/MIC), Class A
EU RoHS Compliant (Directive 2011/65/EU)
China RoHS Compliant
Added Features
Performance Features
Doubling the maximum Fibre Channel link rate from 8Gb to 16Gb and enhanced virtualization capabilities, help support IT “green” initiatives.
Frame-level Multiplexing and out-of-order frame reassembly increases link efficiency and maximizes HBA performance.
Data Protection Features
End-to-end data protection with hardware parity, CRC, ECC and other advanced error checking and correcting algorithms ensure data is safe from corruption.
Enhanced silent data corruption protection provided by T10-Protection Information (T10‑PI). T10-PI provides additional protection against corruption in Oracle Unbreakable Linux environments.
Deployment and Management Features
Universal boot capability allows the appropriate boot environment to be automatically selected for
- Webáruház: Rubinetti Informatika Kft.
- Befogadás: Kiegészítők > Bazár
- Az áruk gyártója: LENOVO
- Áruk elérhetősége: a kérdésben
- Korszerűsített: 27.10.2024
- Az ár: 131 990 Ft
