Compatibility
Intel LGA1851/1700/1200/1151/1150/1155/1156
AMD AM5/AM4
TDP
180W
Overall Dimension
93×78×123mm (L×W×H)
Heatsink Material
4×?6mm Heatpipe (Direct Touch) + Aluminum Fin
Weight
580g (heatsink+fan)
Fan Dimension
92×92×25mm
Fan Speed
600 ~ 2200±10% RPM
Max. Air Flow
45.8CFM
Max. Static Pressure
1.94mmH2O
Noise
25.8dB(A) Max.
Rated Voltage
12VDC (4pin PWM)
Operating Voltage
10.8 ~ 13.2VDC
Started Voltage
7VDC
Rated Current
0.15A
Power Input
1.8W
Bearing Type
Hydraulic
Connector
4Pin PWM
EAN
6931393305769
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 180W Overall Dimension 93×78×123mm (L×W×H) Heatsink Material 4×?6mm Heatpipe (Direct Touch) + Aluminum Fin Weight 580g (heatsink+fan) Fan Dimension 92×92×25mm Fan Speed 600 ~ 2200±10% RPM
Compatibility Intel LGA20XX/1851/1700/1200/115X AMD AM5/AM4 TDP 250W Overall Dimension 120×94×155mm (L×W×H) Heatsink Material 6×?6mm Heatpipe + Copper Base + Aluminum Fin Weight 940g (heatsink+fan) Fan Dimension 120×120×27mm Fan Speed 500±200 ~ 2000±10% RPM Max.
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 230W Overall Dimension 120×75×152mm (L×W×H) Heatsink Material 4 Copper Heatpipe + Aluminum Base + Aluminum Heatsink Weight 730g (heatsink+fan) Fan Dimension 120×120×27mm (2pcs) Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 230W Overall Dimension 120×75×152mm (L×W×H) Heatsink Material 4 Copper Heatpipe + Aluminum Base + Aluminum Heatsink Weight 730g (heatsink+fan) Fan Dimension 120×120×27mm (2pcs) Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 230W Overall Dimension 120×75×152mm (L×W×H) Heatsink Material 4 Copper Heatpipe + Aluminum Base + Aluminum Heatsink Weight 730g (heatsink+fan) Fan Dimension 120×120×27mm (2pcs) Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 270W Overall Dimension 120×142×154mm (L×W×H) Heatsink Material 6×?6mm Heatpipe + Copper Base + Aluminum Fin Weight 1200g (heatsink+fan) Fan Dimension 120×120×27mm (2pcs) Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 270W Overall Dimension 120×142×154mm (L×W×H) Heatsink Material 6×?6mm Heatpipe + Copper Base + Aluminum Fin Weight 1200g (heatsink+fan) Fan Dimension 120×120×27mm (2pcs) Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 270W Overall Dimension 120×142×154mm (L×W×H) Heatsink Material 6×?6mm Heatpipe + Copper Base + Aluminum Fin Weight 1200g (heatsink+fan) Fan Dimension 120×120×27mm (2pcs) Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 270W Overall Dimension 120×142×154mm (L×W×H) Heatsink Material 6×?6mm Heatpipe + Copper Base + Aluminum Fin Weight 1200g (heatsink+fan) Fan Dimension 120×120×27mm (2pcs) Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1700/1200/2066/2011/1151/1150/1155/1156 AMD AM4 TDP 180W Overall Dimension 120×75×153mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 830g Fan Dimension 120×120×25mm Fan Speed 500±200~1500±10%RPM(PWM)(ARGB) Max.
Compatibility Intel LGA2066/2011/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 200W Overall Dimension 126×90×154mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 950g Fan Dimension 120×120×25mm Fan Speed 500~1500±10%RPM(PWM)(ARGB) Ma
Compatibility Intel LGA2066/2011/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 200W Overall Dimension 126×90×154mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 950g Fan Dimension 120×120×25mm Fan Speed 500~1500±10%RPM(PWM)(ARGB) Ma
Compatibility Intel LGA1700/1200/2066/2011/1151/1150/1155/1156 AMD AM4 TDP 180W Overall Dimension 120×75×153mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 830g Fan Dimension 120×120×25mm Fan Speed 500±200~1500±10%RPM(PWM)(ARGB) Max.
Compatibility Intel LGA2066/2011/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 250W Overall Dimension 129×106×154mm (L×W×H) Heatsink Material 6×?6mm Heatpipe+Copper Base+Aluminum Fin Weight 1300g Fan Dimension 120×120×25mm Fan Speed 500~1500±10%RPM(PWM)(ARGB) Max.
Compatibility Intel LGA2066/2011/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 250W Overall Dimension 129×106×154mm (L×W×H) Heatsink Material 6×?6mm Heatpipe+Copper Base+Aluminum Fin Weight 1300g Fan Dimension 120×120×25mm Fan Speed 500~1500±10%RPM(PWM)(ARGB) Max.
