PN UPCMCOP910HASCG01B
EAN6422956010256
Power
1000 VA/900 W
Type
On-line
Nominal Input Voltage
208/220/230/240 VAC
Accepted Input Voltage Range
80-300 VAC
Nominal Output Voltage
208/220/230/240 VAC - user selectable
Frequency
50 Hz/60 Hz
Efficiency
High efficiency up to 97%
Outlets
Input 1 x IEC-320 C14
Output 8 x IEC-320 C13
Transfer Time to Battery / AC
Zero
Typical Backup Time
25% Load - 23min 6sec
50% Load - 10min 8sec
75% Load - 5min 37sec
100% Load - 3min 38sec
Communication Ports
HID USB / RS232 / EPO / SNMP EBM (optional)
Software
http://www.powermonitor. software/
Battery Type
Sealed and leak proof maintenance
Battery Specification
3 X GP07122L
Features
Internal bypass
EPO function
Multifunctional color LCD
Output Power Factor 0.9
Generator compatible
ECO Mode for energy saving
Software management
Rack/Tower design
Easy Battery Replacement
External battery pack (optional)
LCD Display
UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions
Environment
0- 40°C (non-condensing)
Physical Dimensions
438 x 430 x 88 mm
Weight: 13.7 kg
24 hó, 1000VA, Line interactive, Torony / Rack, RS232 / USB (opcionális), LCD
PN UPLI-LI120AG-CG01B EAN6422956009458 Power 1200 VA / 720 W Type Line Interactive Nominal Input Voltage 230 VAC Nominal Output Voltage 230 VAC Accepted Input Voltage Range 162-290 VAC Frequency 50 / 60 Hz Auto detection Outlets 4 x IEC C13 outlets with protection Transfer Time to Battery / AC
12+12 hó, 1000VA (900W), On-line, Rack, RS232 / USB, LCD
1000VA, Line interactive, Rack, RS232 / USB, LCD, 1/1
A termék NEM tartalmazza, az akkumulátorokat, és a tárolóegységet! PN PWUP-OL10KBA-AZ01B EAN6422956006297 Type On-line Power 10000 VA / 10000 W Nominal Input Voltage 208/220/230/240 VAC Nominal Output Voltage 208/220/230/240 VAC Frequency 46~54 Hz la 50Hz Transfer Time to Battery / AC Zero Efficiency Up to 94% efficiency rate Communication Port RS232 / USB / Intelligent Port (nu e inclus in pachet) Battery Type Battery not included Depen
12+12 hó, 1000VA (900W), On-line, Torony, RS232 / USB, LCD
Power 2200 VA / 1320 W Type Line Interactive Nominal Input Voltage 230 Vac Accepted Input Voltage Range 165 - 290 VAC Nominal Output Voltage 230 Vac Frequency 50Hz ~ 60 Hz (Auto sensing) Transfer Time to Battery / AC < 4 ms LCD Display Load level, Battery level, AC mode, Battery mode and Fault indicators Outlets 4 x IEC C13 outlets with protection Battery Type Sealed and leak proof maintenance Battery Specification 12V 9Ah x 2 Battery Compatibility PW9123 Typical Backup Time 25% Load - 17 min
Power 3000 VA / 1800 W Type Line Interactive Nominal Input Voltage 230 Vac Accepted Input Voltage Range 165 - 290 VAC Nominal Output Voltage 230 Vac Frequency 50Hz ~ 60 Hz (Auto sensing) Transfer Time to Battery / AC < 4 ms LCD Display Load level, Battery level, AC mode, Battery mode and Fault indicators Outlets 8 x IEC C13 Battery Backup Surge Protection Battery Type Sealed and leak proof maintenance Battery Specification 12V 7.5Ah x 4 Battery Compatibility PW9123 Typical Backup Time 25% Loa
24 hó, 1000VA, On-line, Torony / Rack, RS232 / USB, LCD
PN UPCMCOP110HBAAZ01B EAN6422956011413 Power 1000 VA / 1000 W Type On-line Nominal Input Voltage 230 VAC Accepted Input Voltage Range 110-300 VAC ± 5% @ 50% load 160-300 VAC ± 5% @ 100% load Nominal Output Voltage 200*/208*/220/230/240 VAC *Derate capacity to 80% when the output voltage is adjusted to 200VAC/208VAC Frequency 40Hz ~ 70 Hz Outlets Input: 1 x IEC-320 C14 Output: 8 x IEC-320 C13 Transfer Time to Battery / AC Zero Efficiency H
PN PWUP-OL150BA-AZ01B EAN6422956007850 Power 1500 VA / 1500 W Type On-line Nominal Input Voltage 230Vac Nominal Output Voltage 200*/208*/220/230/240 VAC *Derate capacity to 80% when the output voltage is adjusted to 200VAC/208VAC Accepted Input Voltage Range 110-300 VAC ± 5% @ 50% load 160-300 VAC ± 5% @ 100% load Frequency 40Hz ~ 70 Hz Transfer time AC-DC: Zero Inverter to Bypass: 4ms Efficiency High efficiency up to 96% Typical Backup Time
PN PWUP-OL300BA-AZ01B EAN6422956007867 Power 3000 VA / 3000 W Type On-line Nominal Input Voltage 230Vac Nominal Output Voltage 200*/208*/220/230/240 VAC *Derated capacity to 80% when the output voltage is adjusted to 200VAC/208VAC Accepted Input Voltage Range 110-300 VAC ± 5% @ 50% load 160-300 VAC ± 5% @ 100% load Frequency 40Hz ~ 70 Hz Transfer time AC-DC: Zero Inverter to Bypass: 4ms Typical Backup Time 25% Load - 26 min 50% Load - 11 min
PN PWUP-OL100AP-AZ01B EAN6422956007713 Power 1000VA / 900W Type On-line Nominal Input Voltage 110-300 Vac Nominal Output Voltage 230 Vac Accepted Input Voltage Range ±1% (in Battery Mode) Frequency 40Hz ~ 70Hz Outlets 3 Outlets with Battery Backup Surge Protection Transfer time AC-DC: Zero Inverter to Bypass: 4ms LCD Display AC Mode, Battery Mode, Load Level, Battery Level, Input Voltage, Output Voltage, Overload, Fault and Low Battery
12+12 hó, 3000VA (2400W), On-line, Rack, RS232 / USB, LCD
**KSTAR Micropower 1000VA USB LED Line-interaktív szünetmentes tápegység** A KSTAR Micropower 1000VA USB LED Line-interaktív szünetmentes tápegység egy megbízható és hatékony megoldás, amely biztosítja az Ön elektronikai eszközeinek védelmét. A 1000VA névleges teljesítményével ideális választás otthoni és irodai környezetbe is, ahol a folyamatos áramellátás létfontosságú. Ez a tápegység line-interaktív technológiával rendelkezik, amely lehetővé teszi a feszültség optimalizálását, így minimalizálva a fes
