Compatibility
Intel LGA1700/1200/1151/1150/1155/1156
AMD AM5/AM4
TDP
220W
Overall Dimension
120×73×152mm (L×W×H)
Heatsink Material
4×?6mm Heatpipe(Direct Touch)+Aluminum Fin
Weight
720g (heatsink+fan)
Fan Dimension
120×120×25mm
Fan Speed
500±200~2000±10%RPM
Max. Air Flow
78.25CFM
Max. Static Pressure
2.68mmH2O
Noise
29.85dB(A) Max.
Rated Voltage
12VDC (4pin PWM)
Operating Voltage
10.8~13.2VDC
Started Voltage
7VDC
Rated Current
0.25A
Power Input
3W
Bearing Type
Hydraulic Bearing
Connector
4Pin PWM
EAN
6931393305622
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 230W Overall Dimension 120×75×152mm (L×W×H) Heatsink Material 4 Copper Heatpipe + Aluminum Base + Aluminum Heatsink Weight 730g (heatsink+fan) Fan Dimension 120×120×27mm (2pcs) Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 230W Overall Dimension 120×75×152mm (L×W×H) Heatsink Material 4 Copper Heatpipe + Aluminum Base + Aluminum Heatsink Weight 730g (heatsink+fan) Fan Dimension 120×120×27mm (2pcs) Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 230W Overall Dimension 120×75×152mm (L×W×H) Heatsink Material 4 Copper Heatpipe + Aluminum Base + Aluminum Heatsink Weight 730g (heatsink+fan) Fan Dimension 120×120×27mm (2pcs) Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 180W Overall Dimension 93×78×123mm (L×W×H) Heatsink Material 4×?6mm Heatpipe (Direct Touch) + Aluminum Fin Weight 580g (heatsink+fan) Fan Dimension 92×92×25mm Fan Speed 600 ~ 2200±10% RPM
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 180W Overall Dimension 93×78×123mm (L×W×H) Heatsink Material 4×?6mm Heatpipe (Direct Touch) + Aluminum Fin Weight 580g (heatsink+fan) Fan Dimension 92×92×25mm Fan Speed 600 ~ 2200±10% RPM
Compatibility Intel LGA1700/1200/1151/1150/1155/1156/2011 AMD AM5/AM4 TDP 250W Overall Dimension 120×92×155mm (L×W×H) Heatsink Material 6×?6mm Heatpipe + Copper Base + Aluminum Fin Weight 925g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1700/1200/1151/1150/1155/1156/2011 AMD AM5/AM4 TDP 250W Overall Dimension 120×92×155mm (L×W×H) Heatsink Material 6×?6mm Heatpipe + Copper Base + Aluminum Fin Weight 925g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA20XX/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 300W Overall Dimension 140×153×163mm (L×W×H) Heatsink Material 7×?6mm Heatpipe + Copper Base + Aluminum Fin Weight 1300g (heatsink+fan) Fan Dimension 140×140×25mm (2pcs) Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA20XX/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 300W Overall Dimension 140×153×163mm (L×W×H) Heatsink Material 7×?6mm Heatpipe + Copper Base + Aluminum Fin Weight 1300g (heatsink+fan) Fan Dimension 140×140×25mm (2pcs) Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 270W Overall Dimension 120×140×154mm (L×W×H) Heatsink Material 4×?6mm Heatpipe+Copper Base+Aluminum Fin Weight 1190g (heatsink+fan) Fan Dimension 120×120×25mm (2pcs) Fan Speed 500±200~2000±10%RPM
Compatibility Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 270W Overall Dimension 120×140×154mm (L×W×H) Heatsink Material 4×?6mm Heatpipe+Copper Base+Aluminum Fin Weight 1190g (heatsink+fan) Fan Dimension 120×120×25mm (2pcs) Fan Speed 500±200~2000±10%RPM
Compatibility Intel LGA20XX/1851/1700/1200/115X AMD AM5/AM4 TDP 250W Overall Dimension 120×94×155mm (L×W×H) Heatsink Material 6×?6mm Heatpipe + Copper Base + Aluminum Fin Weight 940g (heatsink+fan) Fan Dimension 120×120×27mm Fan Speed 500±200 ~ 2000±10% RPM Max.
Compatibility Intel LGA1700/1200/2066/2011/1151/1150/1155/1156 AMD AM4 TDP 250W Overall Dimension 129×106×154mm (L×W×H) Heatsink Material 6×?6mm Heatpipe+Copper Base+Aluminum Fin Weight 1300g Fan Dimension 120×120×25mm Fan Speed 700+-200~1800±10%RPM(PWM) Max. Air
Compatibility Intel LGA1700/1200/2066/2011/1151/1150/1155/1156 AMD AM4 TDP 250W Overall Dimension 129×106×154mm (L×W×H) Heatsink Material 6×?6mm Heatpipe+Copper Base+Aluminum Fin Weight 1300g Fan Dimension 120×120×25mm Fan Speed 700+-200~1800±10%RPM(PWM) Max. Air
Compatibility Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 220W Overall Dimension 120×75×151mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 650g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 600±200~1500±10%RPM Max. A
