Compatibility
Intel LGA1700/1200/2066/2011/1151/1150/1155/1156
AMD AM4
TDP
250W
Overall Dimension
129×106×154mm (L×W×H)
Heatsink Material
6×?6mm Heatpipe+Copper Base+Aluminum Fin
Weight
1300g
Fan Dimension
120×120×25mm
Fan Speed
700+-200~1800±10%RPM(PWM)
Max. Air Flow
76.16CFM
Max. Static Pressure
2.16mmH2O
Noise
15.2-35.2dB(A)
Rated Voltage
12VDC (4pin PWM)
Operating Voltage
10.8~13.2VDC
Started Voltage
7VDC
Rated Current
0.2A
Power Input
2.4W
Bearing Type
Hydraulic Bearing
Connector
4Pin PWM
Compatibility Intel LGA1700/1200/2066/2011/1151/1150/1155/1156 AMD AM4 TDP 250W Overall Dimension 129×106×154mm (L×W×H) Heatsink Material 6×?6mm Heatpipe+Copper Base+Aluminum Fin Weight 1300g Fan Dimension 120×120×25mm Fan Speed 700+-200~1800±10%RPM(PWM) Max. Air
Compatibility Intel LGA1700/1200/2066/2011/1151/1150/1155/1156 AMD AM4 TDP 250W Overall Dimension 129×106×154mm (L×W×H) Heatsink Material
Compatibility Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 220W Overall Dimension 120×75×151mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 650g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 600±200~1500±10%RPM Max. A
Compatibility Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 220W Overall Dimension 120×75×151mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 650g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 600±200~1500±10%RPM Max. A
Compatibility Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 180W Overall Dimension 120×76×134mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 690g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 700±200~1600±10%RPM Max.
Compatibility Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 125W Overall Dimension 120×120×55mm (L×W×H) Material 5×?6mm heatpipe+Copper Base+Aluminum Fin (Black coating) Weight 450g (Heastink+fan) Fan Dimension 120×120×15mm Fan Speed 500-2000RPM(PWM)
Compatibility Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 220W Overall Dimension 120×73×152mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 720g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 500±200~2000±10%RPM Max. A
Compatibility Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 220W Overall Dimension 120×75×151mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 650g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 600±200~1500±10%RPM Max. A
Compatibility Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 220W Overall Dimension 120×75×151mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 650g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 600±200~1500±10%RPM Max. A
Compatibility Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 220W Overall Dimension 120×75×151mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 650g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 600±200~1500±10%RPM Max.
Compatibility Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 220W Overall Dimension 120×75×151mm (L×W×H) Heatsink Material 4×?6mm Heatpipe(Direct Touch)+Aluminum Fin Weight 650g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 600±200~1500±10%RPM Max.
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 180W Overall Dimension 93×78×123mm (L×W×H) Heatsink Material 4×?6mm Heatpipe (Direct Touch) + Aluminum Fin Weight 580g (heatsink+fan) Fan Dimension 92×92×25mm Fan Speed 600 ~ 2200±10% RPM
Compatibility Intel LGA1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 TDP 180W Overall Dimension 93×78×123mm (L×W×H) Heatsink Material 4×?6mm Heatpipe (Direct Touch) + Aluminum Fin Weight 580g (heatsink+fan) Fan Dimension 92×92×25mm Fan Speed 600 ~ 2200±10% RPM
Compatibility Intel LGA1700/1200/1151/1150/1155/1156/2011 AMD AM5/AM4 TDP 250W Overall Dimension 120×92×155mm (L×W×H) Heatsink Material 6×?6mm Heatpipe + Copper Base + Aluminum Fin Weight 925g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1700/1200/1151/1150/1155/1156/2011 AMD AM5/AM4 TDP 250W Overall Dimension 120×92×155mm (L×W×H) Heatsink Material 6×?6mm Heatpipe + Copper Base + Aluminum Fin Weight 925g (heatsink+fan) Fan Dimension 120×120×25mm Fan Speed 500±200 ~ 2000±10% RPM
Compatibility Intel LGA1700/1200/2066/2011/1151/1150/1155/1156 AMD AM4 TDP 250W Overall Dimension 129×106×154mm (L×W×H) Heatsink Material 6×?6mm Heatpipe+Copper Base+Aluminum Fin Weight 1300g Fan Dimension 120×120×25mm Fan Speed 900+-200~2000±10%RPM(PWM)(RGB) Max.
